Birmingham Double Pinch Plate Roll
Each Pinch Roll Has LED Readout Indicators
For Displaying Roll Position
Birmingham Double Pinch Plate Roll
Hydraulic Drop End For Easy Removal
Of Workpiece
New
Machine Tools
by Name Brand are
Listed Below
Select a Link To
Go
to the Index Page
of Your Choice
B U C K' S P R E C I S I O N M A C H I N E T O O L S
G U N T E R S V I L L E, A
L A B A M A 3 5 9 7 6
TEL: 2 5 6 - 5 8 2 - 5 3 5 3 www.buckspmt.com
BIRMINGHAM 5 Ft x 3/8 Double Pinch Plate Roll , Hydraulic
Model RH-0510
Birmingham Double Pinch Hydraulic Plate Bending Roll
Each Of The Lower
Pinch Rolls Has Its Own LED Indicator For Displaying Roll Position
All
Rolls Are Hardened Up To HRC55
All Three Rolls Are Driven Independently
And Hydraulically
Rolls Are Manufactured In A Camber Design To Offset Any
Deformation Of The Workpiece During The Rolling Process
FOR ADDITIONAL INFORMATION OR TO REQUEST A QUOTE CONTACT:
DAN BUCHANAN
TEL: 256-582-5353
We Always Discount !
Description and Features:
OPTIONS:
Variable Speed Roll Rotation
Cone Bending Attachment
Copyright | B U C K S P R E C I S I O N
M A C H I N E T O O L S | A l l R i g h t s
R e s e rv e d
BIRMINGHAM 5 Ft x 3/8 Double Pinch Hydraulic Plate Roll , Model RH-0510
- Capacity:
5' 1" x 3/8" Mild Steel
- Roll Diameter: 10"
- Main Motor: 7.5 HP
- Roll
Speed: 177 Inches / Minute
- Net Weight: 13,000 Lb
- All Three Rolls Are Driven Independently
And Hydraulically
- Forward / Reverse Roll Movement
- Each Of The Lower Pinch Rolls
Has Its Own LED Indicator For Displaying Roll Position
- All Rolls Are Hardened
Up To HRC55
- Rolls Are Manufactured In A Camber Design To Help Offset
Deformation Of The Workpiece During The Rolling Process
- Hydraulically Tilted
Drop End For Easy Removal Of Workpiece
- Hydraulic Circuits Protect Against
Overload And Are Fully Enclosed To Provide A Low Noise And Leak
Proved System
- Sperical High Quality Sealed-In Roller Bearings Protect Against
Dirt & Dust And Are Installed On All Rolls
- Planetary Reduction Gear
& Pump Output High Torque For Smooth And Powerful Roll Rotation
